LG 43″ Signage Display, Model No. 43UH5N-E

55000.00

The ultra high resolution of the UH5N-E is an astounding innovation for the business sector and for society in general because it makes images so distinct that they are four times more clear than what FHD could ever present.

About this item

  • Stunning Visuals:- Those who experience the picture quality will find it incredible it being 4 times denser than the pixels of Full HD resolution.
  • Efficient Operation:- High-performance SoC of the monitor/multimedia Player can perform multumping and does not need external media players.
  • Reliable Durability:- Conformal coating makes it resistant to salt, dust, iron powder and humidity enabling it to perform in a stable manner.
  • Space-Saving Design:- Close-to-wall mounting (more like flush mounting) is made possible due to the slim bezels and concealed power inlets.
  • Advanced Security:- LG’s EKP technology keeps off thorny eyeballs as well as prying fingers from sensitive information.
  • Sustainability Commitment:- LG does not hesitate to go Green for the sake of making a better tomorrow.
  • Smart Content Management:- Super Sign Solutions aids in creating and managing digital signage and improves user interaction.

The ultra high resolution of the UH5N-E is an astounding innovation for the business sector and for society in general because it makes images so distinct that they are four times more clear than what FHD could ever present. Being backed by an advanced SoC, it can carry out multiple functions at the same time with no external media player assisting it, which is a way of improving productivity. The UH5N-E, which was designed to last, was tailored for the business sector, broadening its reach, it has a conformal coat on the power board enabling it to shield against salt, dust, iron powder, humidity, among other environmental conditions. It’s worth noting that the device’s aesthetic features sophisticated highly effective cable management as well as ultra-thin bezels which allows for very close attachment to the wall, about 13 millimeters when a narrow mount is used. Protection of vital functions as well as information is further ensured by calling on LG EKR (Enhanced kernel protection-Round Core), paired up with other more advanced features describing data security as more advanced undermined access and threats from outside.

PANEL

Screen Size (Inch):- 109.22cm (43)
Panel Technology:- IPS
Back Light Type:- Edge
Aspect Ratio:- 16 : 9
Native Resolution:- 3840×2160 (UHD)
Refresh Rate:- 60Hz
Brightness:- 500nit (Typ.)
Dynamic CR:- 1,000,000:110bit(D), 1.07Billion colors
Color Gamut:- BT709 95%
Viewing Angle (H x V):- 178 x 178
Color Depth (Number of Colors):- 10bit(D), 1.07Billion colors
Response Time:- Tr : 8ms / Tf :10ms
Surface Treatment (Haze):- 28%
Operation Hours (Hours/Day):- 24/7
Portait / Landscape:- Yes / Yes

CONNECTIVITY

HDMI In:- Yes(3), 3840×2160@60Hz, HDCP 2.2/1.4
DP In:- Yes(1), 3840×2160@60Hz, HDCP2.2/1.3
RS232C In:- Yes(1), 4pin PhYesne-jack
RJ45(LAN) In:- Yes(1)
IR In:- Yes(1)
USB In:- USB2.0 Type A(1)
HDMI Out:- Yes(1), 3840×2160@30Hz, Input : HDMI1/2/3/DP
Audio Out:- Yes(1)
RS232C Out:- Yes(1), 4pin PhYesne-jack
Daisy Chain:- Yes(Input HDMI, DP / Yesutput HDMI)

MECHANICAL SPECIFICATION

Bezel Color:- Black
Bezel Width:- T/R/L: 8.9mm, B: 12.9mm
Weight (Head):-11.1 kgs
Packed Weight:- 12.8 kgs
Monitor Dimensions (W x H x D):- 963.0 x 556.2 x 29.7mm (without IR)
VESA Standard Mount Interface:- 200 x 200
Carton Dimensions (W x H x D):- 1055.0 x 660.0 x 142.0mm

FEATURE - HARDWARE

Internal Memory (eMMC):- 16GB
Wi-Fi/BT (Built-in):- Yes
Temperature Sensor:- Yes
Auto Brightness Sensor:- Yes( IR)
Acceleration(Gyro) Sensor:- Yes
Local Key Operation:- Yes

FEATURE - SOFTWARE

OS Ver. (webOS):- webOS 6.0
Local Contents Scheduling:- Yes
Group Manager:- Yes
USB Plug & Play:- Yes
Fail Over:- Yes
Booting Logo Image:- Yes
No Signal Image:-Yes
RS232C Sync:- Yes
Local Network Sync:- Yes
PIP:- Yes
PBP:- Yes(4)
Screen Share:- Yes
Video Tag:- Yes(4)
Play Via URL:- Yes
Screen Rotation:- Yes
External Input Rotation:- Yes
Gapless Playback:- Yes
Tile Mode Setting:- Yes (Max. 15×15)
Setting Data Cloning:- Yes
SNMP:- Yes
ISM Method:- Yes
Auto Set ID:- Yes
Status Mailing:- Yes
Control Manager:- Yes
Cisco Certification:- Yes
Crestron Connected:- Yes
Smart Energy Saving:- Yes
PM mode:- Yes
Wake on LAN:- Yes
Network Ready:- Yes
BEACON:- Yes
HDMI-CEC:- Yes
SI Server Setting:- Yes
webRTC:- Yes
Pro:Idiom:- Yes

ENVIRONMENT CONDITIONS

Operation Temperature:- 0 °C to 40 °C
Operation Humidity:- 10 % to 80 %

POWER

Power Supply:- AC 100-240V~, 50/60Hz
Power Type: Built-In Power

POWER CONSUMPTION

BTU (British Thermal Unit):- 273 BTU/Hr(Typ.), 409 BTU/Hr(Max)
Smart Energy Saving (70%):- 56W
DPM:- 0.5W
Power off:- 0.5W
Max.:- 120W
Typ.:- 80W

SOUND

Speaker (Built-in):- Yes

CERTIFICATION

Safety:- CB / NRTL
EMC:- FCC Class "B" / CE / KC
ERP / Energy Star:- Yes (NewErP) / Yes
ePEAT(US only):- Yes

SOFTWARE COMPATIBILITY

SuperSign CMS:- Yes
SuperSign Control+:- Yes / Yes
SuperSign WB:- Yes
SuperSign Cloud:- Yes
Mobile CMS:-Yes
Connected Care:- Yes

LANGUAGE

OSD:- English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Turkish→Türkiye, Arabic

ACCESSORY

Basic:- Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(2EA), AC Cord Holder (1EA)
Optional:- Slim Wall Mount (WB21LMA/B), Wall Mount (OLW480A/B) Wall Mount Adapter (AM-B330S)

SPECIAL FEATURE

Tilt (Face down):- Yes(Max 30º degree, 40ºC temperature)
IP Rating:- IP5x
Conformal Coating (Power Board):- Yes
