LG CreateBoard , 55″ Interactive Flat Panel, Model No. 55TR3DK
₹300000.00
The all-in-one LG Create Board is designed for learning environments and includes several teaching templates such as rulers, tables and sticky notes, which help in increasing interaction from the students and make learning easier.
About this item
- Teaching Tools & Templates:- Provides a like ruler, tables, sticky notes and other teaching tools for enriching the classes. It is easy to modify and distribute the materials using QR codes.
- Multi-Touch:- Recognizes 40 touch points enabling real experience which is vital for learner’s attention.
- Seamless File Management:- Files can be saved, imported and exported using USB ports, google drive and onedrive.
- LG ConnectedCare DMS:- Control and supervise classroom devices to ease the operations from one place.
- Remote Management:- Control power requirements and brightness, scheduling broadcasts, alerts for emergencies, etc.
- Google Integration:- Certified through Google and can use other universal applications accessible in Google play store.
- Wireless ScreenShare:- Up to 9 screens can be displayed on connected devices and files can be shared easily.
- Bluetooth & USB Type-C:- Use Bluetooth for peripherals and charge or transfer data via USB-C cable for easy utilization and connection.
- QR Login:- QR code provides seamless security while accessing the cloud which makes class preparation easy.
- Eye Care & Comfort:- Advanced flicker free technology provides comfort during prolonged use.
- Front Connectivity:- Has built speakers and front ports which are very easy to reach for convenience.
- Built-in OPS Slot:- Integrate desktops easily without need of connecting wires on the outside.
- Smart Viewing:- Multiple materials can be viewed all at once on a single screen.
- Power & Screen Security:- Power saving mode avoids wasting energy and Screen Lock plus Secure Mode prevent unauthorized access.
- USB Lock Mode:- Prevents data copying by an unauthorized user in safe environments.
The all-in-one LG Create Board is designed for learning environments and includes several teaching templates such as rulers, tables and sticky notes, which help in increasing interaction from the students and make learning easier. The multi-touch capability allows up to 40 simultaneous touch points which improves students’ involvement and concentration. Importing and exporting files from Google Drive, One Drive, and USB flash drives is easy and efficient.LG CreateBoard as the learning aid can use easily monitor and operate LG’s ConnectedCares stimulator management system without actually visiting the sites. Commands such as the power on/off, brightness adjustment, or screen lock can be remotely commanded as well as content such as images, videos, or live broadcasts over phones can be displayed. With such functions available, emergency notifications in case of disruption from the system can also be sent out to enable safety measures. Integration of Google Certification and Google Play Store facilitates easy access to the entire range of Google offerings and all the teaching applications. The Wireless Screen Share feature enhances collaborative learning by allowing up to 9 screens or files to be shared at the same time. Various wireless peripherals improve the ease of hybrid teaching environments, and USB C makes connections for charging and data transfer more efficient.
| PANEL | Screen Size (Inch):- 55 Native Resolution:- 3840 x 2160 (UHD) Color Gamut:- NTSC 72% Surface Treatment (Haze):- Haze 25% Panel Technology:- IPS Refresh Rate:- 60Hz Viewing Angle (H x V):- 178º x 178º Operation Hours (Hours/Day):- 16/7 Back Light Type:- Direct Brightness:- 440 nits Color Depth (Number of Colors):- 16.7 Million colors Portait / Landscape:- NO / YES Aspect Ratio:- 16:9 Dynamic CR:- 5,000:1 Response Time:- 8ms (G to G) |
|---|---|
| CONNECTIVITY | HDMI In:- YES (3ea) RGB In:- YES IR In:- NO Audio Out:- YES RJ45(LAN) Out:- YES HDMI In (HDCP Ver.):- 2.2 Audio In:- YES USB In:- USB3.0 Type A (4ea), USB2.0 Type A (1ea), USB Type C (1ea) Touch USB:- USB2.0 Type B (2ea) DP In:- NO RS232C In:- YES HDMI Out:- YES External Speaker Out:- NO DVI-D In:- NO RJ45(LAN) In:- YES (1ea) DP Out:- NO RS232C Out:- NO |
| MECHANICAL SPECIFICATION | Bezel Color:- Black Monitor Dimensions (W x H x D):- 1271 × 774 × 87mm Bezel Width:- T/R/L/B : 18/18/18/45mm Handle:- NO Weight (Head):- 26.1Kg VESA Standard Mount Interface:- 400 x 200 mm Packed Weight:- 34.5Kg Carton Dimensions (W x H x D):- 1401 × 859 × 220mm |
| FEATURE - HARDWARE | Internal Memory (eMMC):- 32GB Power Indicator:- YES Wi-Fi/BT (Built-in):- YES Local Key Operation:- NO Temperature Sensor:- NO Auto Brightness Sensor:- YES |
| FEATURE - SOFTWARE | Booting Logo Image:- YES Setting Data Cloning:- NO Wake on LAN:- YES PIP:- YES Crestron Connected:- NO Network Ready:- NO PBP:- YES (2PBP) Smart Energy Saving:- YES HDMI-CEC:- NO Screen Share:- YES PM mode:- NO |
| ENVIRONMENT CONDITIONS | Operation Temperature:- 0 °C to 40 °C Operation Humidity:- 10 % to 90 % |
| POWER | Power Supply:- AC 100-240V~, 50/60Hz Power Type:- Built-in Power |
| POWER CONSUMPTION | BTU (British Thermal Unit):- 580 BTU/Hr(Typ.), 1348 BTU/Hr(Max.) Typ.:- 170W DPM:- 0.5W Power off:- 0.5W Max.:- 395W |
| SOUND | Speaker (Built-in):- YES (15W x 2) |
| CERTIFICATION | Safety:-CB / NRTL EMC:- FCC Class "A" / CE ERP / Energy Star:- YES / NO |
| OPS COMPATIBILITY | OPS Type compatible:- YES (Slot) OPS Power Built-in:- YES |
| SOFTWARE COMPATIBILITY | Connected Care:- YES |
| LANGUAGE | OSD:- English, Denmark, Finnish, German, Korean, Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Spanish, Swedish, Hungarian, Thai |
| ACCESSORY | Basic:- Power Cord 3M*1, USB Cable (Type A-Type B) 5M*1, HDMI Cable 3M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module Optional:- Wall Mount(WM-L000S), Floor Stand(ST-000F, ST-860F) |
| SPECIAL FEATURE | Conformal Coating (Power Board):- YES |
| DEDICATED FEATURE - TOUCH | Available Object Size for Touch:- Ø2 mm ↑ Protection Glass Thickness:- 3mm (Anti-Glare) Response Time ('Paint' app on Windows 10 PC):- 5ms ↓ Protection Glass Transmission:- 0.88 Accuracy (Typ.):- ±1mm Operating System Support:- Windows 7/8/10/Linux/Mac/Android (Linux/Mac Support one point touch) Interface:- USB2.0 Multi Touch Point:- Max. 40 Points(Windows), Max. 32 Points(Android) |
| DEDICATED FEATURE - CREATE BOARD | CPU:- Quad core A55 Wi-Fi:- 802.11a/b/g/n/ac/ax (WiFi 6) GPU:- Mail G52 Multicore 2 LAN:- Gigabit LAN Memory(RAM):- 8GB Bluetooth:- Bluetooth 5.0 Storage:- 64GB OS ver. (Android):- Android 13 |
