LG 55″ UHD Signage Display, Model No. 55UH7N-E

₹85000.00

Ensuring an impressive display and performance like no other the LG UH7N-E digital signage offers a resolution which is 4 times higher than that of FHD’s allowing users without a doubt a one of a kind viewing.

About this item

  • Ultra High Resolution:- Impressive image detail, four times clearer than FHD.
  • Powerful webOS Platform:- The built-in SoC allows users to run multiple applications without the need for external media players.
  • Reliable Durability:- The coating protects the device from environmental issues like salt, dust or humidity.
  • Space-Efficient Design:- Having thin bezels and tidy cable routing or concealing power sockets with a mere 13 mm distance enables wall mounting.
  • Advanced Security:- Critical information is fortified from intrusions by LG’s Enhanced Kernel Protection–EKP.
  • Eco-Friendly Manufacturing:- Back covers containing recycled resins, enhancing eco-friendly production practices.*
  • Super Sign Solutions:- Easy content management system for designing and managing professional appealing digital displays.
  • Low Carbon Footprint:- Decreased environmental impacts from production to disposal of the product.

Ensuring an impressive display and performance like no other the LG UH7N-E digital signage offers a resolution which is 4 times higher than that of FHD’s allowing users without a doubt a one of a kind viewing. Thanks to the SoC which is integrated into the system and a fantastic webOS platform you are able to multitask at ease without needing to plug in a media player which can be incredibly helpful in a variety of workplaces. The longevity of the product has also been ensured as the power board has been designed with a conformal coating that protects the device against salt water, dust, iron powder, and humidity. In addition to that the design is incredibly minimalist as the bezels are extremely thin along with hidden power inlets which offers an aesthetically pleasing close-to-wall installation. In order to keep information protected LG has made it a priority to adopt Enhanced Kernel Protection (EKP) technology that will protect data access.

PANEL

Screen Size (Inch):- 55
Panel Technology:- IPS
Back Light Type:- Edge
Aspect Ratio:- 16:9
Native Resolution:- 3840 x 2160 (UHD)
Refresh Rate:- 60Hz
Brightness:- 700nit (Typ.)
Dynamic CR:- 1,000,000:1
Color Gamut:- BT709 95%
Viewing Angle (H x V):- 178 X 178
Color Depth (Number of Colors):- 10bit(D), 1.07Billion colors
Response Time:- 8ms (G to G)
Surface Treatment (Haze):- 28%
Life time:- 50,000Hrs (Min.)
Operation Hours (Hours/Day):- 24/7
Portait / Landscape:- Yes
CONNECTIVITY

HDMI In:- Yes (2), 3840×2160@60Hz, HDCP 2.2/1.4
DP In:- Yes (1), 3840×2160@60Hz, HDCP2.2/1.3
RS232C In:- Yes (1)
RJ45(LAN) In:- Yes (1)
IR In:- Yes (1)
USB In:- USB2.0 Type A(1), USB2.0 Type C ((1), without PD funtion)
DP Out:- Yes (1), 3840×2160@60Hz, Input : HDMI1/2/DP/USB-C
Audio Out:- Yes (1)
RS232C Out:- Yes (1), 4pin Phone-jack
Daisy Chain:- Yes (Input HDMI, DP, USB C / Output DP)
MECHANICAL SPECIFICATION

Bezel Color:- Black
Bezel Width:- T/R/L: 8.9mm, B: 12.9mm
Weight (Head):- 16.1 kg
Packed Weight:- 20.5 kg
Monitor Dimensions (W x H x D):- 1231.4 x 707.2 x 29.7mm (without IR)
VESA Standard Mount Interface:- 300 x 300
Carton Dimensions (W x H x D):- 1360.0 x 801.0 x 161.0mm
FEATURE - HARDWARE

Internal Memory (eMMC):- 16GB
Wi-Fi/BT (Built-in):- Yes
Temperature Sensor:- Yes
Auto Brightness Sensor:- Yes ( External IR)
Acceleration(Gyro) Sensor:- Yes
Local Key Operation:- Yes
FEATURE - SOFTWARE

OS Ver. (webOS):- webOS6.0
Local Contents Scheduling:- Yes
Group Manager:- Yes
USB Plug & Play:- Yes
Fail Over:- Yes
Booting Logo Image:- Yes
No Signal Image:- Yes
RS232C Sync:- Yes
Local Network Sync:- Yes
PIP:- Yes
PBP:- Yes (4)
Screen Share:- Yes
Video Tag:- Yes (4)
Play Via URL:- Yes
Screen Rotation:- Yes
External Input Rotation:- Yes
Gapless Playback:- Yes
Tile Mode Setting:- Yes (Max. 15×15)
Setting Data Cloning:- Yes
SNMP:- Yes
ISM Method:- Yes
Auto Set ID:- Yes
Status Mailing:- Yes
Control Manager:- Yes
Cisco Certification:- (TBD)
Crestron Connected:- Yes
Smart Energy Saving:- Yes
PM mode:- Yes
Wake on LAN:- Yes
Network Ready:- Yes
BEACON:- Yes
HDMI-CEC:- Yes
SI Server Setting:- Yes
webRTC:- Yes
Pro:Idiom:- Yes
ENVIRONMENT CONDITIONS

Operation Temperature:- 0 °C to 40 °C
Operation Humidity:- 10 % to 80 %
POWER

Power Supply:- AC 100-240V~, 50/60Hz
Power Type:- Built-In Power
POWER CONSUMPTION

BTU (British Thermal Unit):- 375 BTU/Hr(Typ.), 546 BTU/Hr(Max)
Smart Energy Saving (70%):- 77
DPM:- 0.5W
Power off:- 0.5W
Max.:- 160W
Typ.:- 110W
SOUND

Speaker (Built-in):- Yes (10W X 2)
CERTIFICATION

Safety:- CB / NRTL
EMC:- FCC Class "B" / CE / KC
ERP / Energy Star:- Yes (NewErP)/Yes
ePEAT(US only):- Yes
SOFTWARE COMPATIBILITY

SuperSign CMS:- Yes
SuperSign Control+:- Yes
SuperSign WB:- Yes
SuperSign Cloud:- Yes
Promota:- Yes (Not available for EU/CIS)
Mobile CMS:- Yes
Connected Care:- Yes
LANGUAGE

OSD:- English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic
ACCESSORY

Basic:- Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, USB-C Cable, Cable Holder(2EA), AC Cord Holder (1EA)
Optional:- Slim Wall Mount (WB21LMA/B), 일반 Wall Mount (OLW480A/B) Wall Mount Adapter (AM-B330S)
SPECIAL FEATURE

Tilt (Face up):- Yes (Max 30˚ degree, 40℃ temperature)
IP Rating:- IP5X
Conformal Coating (Power Board):- Yes
