LG 86″ webOS UHD Signage, Model No. 86UL3J-B

₹210000.00

LG webOS UHD Signage creates a combination of cutting-edge technology and features which can be utilized across a number of industries.


About this item

  • Ultra HD Resolution:- Provides splendid colors and rich details enabling the best picture quality possible.
  • Slim Design:- The compact form factor and thin borders saves space and allows easier mounting.
  • Enhanced Performance:- Smooth interaction through the upgraded SoC and web engine is assured by LG webOS 6.0.
  • Sensor Connectivity:- Allows GPIO, NFC/RFID, and temperature sensors by USB pluggable for custom-made solutions.
  • Wireless Screen Sharing:- LG One:Quick Share offers smooth screen sharing and meeting dynamics with a USB dongle and integrated Wifi.
  • Web-Based Monitoring:- Added ease through the easy remote control and monitoring features.
  • AV System Compatibility:- Professional AV systems can connect with ease thanks to Crestron Connected®.

LG webOS UHD Signage creates a combination of cutting-edge technology and features which can be utilized across a number of industries. With an outstanding contrast ratio due to its IPS panel technology, rich colors and intricacies are further complemented with its ultra high definition resolution. Its flush sleek design with thin bezels and less thickness also saves space while making installation quicker and easier. In addition, the UL3J series is also powered with LG webOS version 6.0 with enhanced SoC and web engine which combines the multitasking performance and lightweight features. The LG webOS has expanded functionality and uses a smart signage platform that can quickly integrate with peripheral devices through a USB interface including GPIO, NFC/RFID and thermal sensors, offering cutting-edge solutions.

PANEL

Screen Size (Inch):- 86
Panel Technology:- IPS
Back Light Type:- Direct
Aspect Ratio:- 16:9
Native Resolution:- 3840 x 2160 (UHD)
Refresh Rate:- 120Hz
Brightness:- 330nit (Typ.)
Dynamic CR:- 1,000,000:1
Color Gamut:- DCI 80%
Viewing Angle (H x V):- 178º x 178º
Color Depth (Number of Colors):- 1.07 Billion colors
Response Time:- 5ms (G to G)
Surface Treatment (Haze):- Haze 3%
Operation Hours (Hours/Day):- 16/7
Portait / Landscape:- NO / YES
Transparency:- N/A
QWP (Quarter Wave Plate):- N/A
CONNECTIVITY

HDMI In:- YES (3ea)
HDMI In (HDCP Ver.):- 2.2/1.4
DP In:- NO
DVI-D In:- NO
RGB In:- NO
Audio In:- NO
RS232C In:- YES
RJ45(LAN) In:- YES (1ea)
IR In:- NO
USB In:- USB2.0 Type A (2ea)
HDMI Out:- NO
DP Out:- NO
Audio Out:- YES
Touch USB:- NO
External Speaker Out:- NO
RS232C Out:- YES
RJ45(LAN) Out:- NO
IR Out:- NO
Daisy Chain:- NO
MECHANICAL SPECIFICATION

Bezel Color:- Ashed Blue
Bezel Width:- Off : 6.9/6.9/6.9/18.4mm On : 15.9/15.9/15.9/19.9mm
Weight (Head):- 45.2Kg
Packed Weight:- 57.7Kg
Monitor Dimensions (W x H x D):- 1927 x 1104 x 59.9mm
Monitor Dimension with Stand (W x H x D):- N/A
Handle:- NO
VESA Standard Mount Interface:- 600 x 400 mm
Carton Dimensions (W x H x D):- 2115 x 1215 x 228mm
Weight (Head+Stand):- N/A
FEATURE - HARDWARE

Internal Memory (eMMC):- 16GB
Wi-Fi/BT (Built-in):- YES
Temperature Sensor:- YES
Auto Brightness Sensor:- YES
Pixel Sensor:- NO
Proximity Sensor:- NO
Current Sensor:- NO
BLU Sensor:- NO
Humidity Sensor:- NO
Acceleration(Gyro) Sensor:- NO
Power Indicator:- NO
Local Key Operation:- YES
FAN (Built-in):- NO
FEATURE - SOFTWARE

OS Ver. (webOS):- webOS 6.0
Local Contents Scheduling:- YES
Group Manager:- YES
USB Plug & Play:- YES
Fail Over:- YES
Booting Logo Image:- YES
No Signal Image:- YES
RS232C Sync:- YES
Local Network Sync:- YES
Backlight Sync:- NO
PIP:- NO
PBP:- NO
Screen Share:- YES
Video Tag:- YES (4 Video Tag)
Play Via URL:- YES
Screen Rotation:- YES
External Input Rotation:- YES
Gapless Playback:- YES
Tile Mode Setting:- YES
Setting Data Cloning:- YES
SNMP:- YES
ISM Method:- YES
Auto Set ID:- YES
Status Mailing:- YES
Control Manager:- YES
Cisco Certification:- YES
Crestron Connected:- YES
Smart Energy Saving:- YES / NO
PM mode:- YES
Wake on LAN:- YES
Network Ready:- YES
BEACON:- YES
HDMI-CEC:- YES
SI Server Setting:- YES
webRTC:- YES
Pro:Idiom:- YES
Brightness Compensation:- NO
W/B Setting by Grey scale:- NO
Scan Inversion:- NO
ENVIRONMENT CONDITIONS

Operation Temperature:- 0 °C to 40 °C (Portrait Scene : 0 °C to 30 °C)
Operation Humidity:- 10 % to 80 %
POWER

Power Supply:- AC 100-240V~, 50/60Hz
Power Type:- Built-in Power
POWER CONSUMPTION

BTU (British Thermal Unit):- 751 BTU/Hr(Typ.), 1024 BTU/Hr(Max.)
Smart Energy Saving (70%):- 154 W
DPM:- 0.5W
Power off:- 0.5W
Max.:- 300W
Typ.:- 220W
SOUND

Speaker (Built-in):- YES (10W x 2)
CERTIFICATION

Safety:- CB / NRTL
EMC:- FCC Class "A" / CE
ERP / Energy Star:- YES / NO
ePEAT(US only):- NO
OPS COMPATIBILITY

OPS Type compatible:- NO
OPS Power Built-in:- NO
SOFTWARE COMPATIBILITY

SuperSign CMS:- YES
SuperSign Control+:- YES
SuperSign WB:- YES
SuperSign Cloud:- NO
Promota:- YES (Not available for EU/CIS)
Mobile CMS:- NO
Connected Care:- YES
LANGUAGE

OSD:- English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic, polski
ACCESSORY

Basic:- Remote Controller(include battery 2ea), Power Cord, Regulation Book, Phone to D-Sub9 Gender, Cable Holder
Optional:- NO
SPECIAL FEATURE

Overlay Touch Compatibility:- N/A
Smart Calibration:- N/A
Tilt (Face up):- N/A
Tilt (Face down):- N/A
IP Rating:- N/A
Conformal Coating (Power Board):- YES
Power Protection:- N/A
Direct Sunlight:- N/A
